Type
Ducati V2 engine: 90° V2, 4 valves per cylinder, intake variable valves timing system, liquid cooled
Displacement
890 cc (54.3 cu in)
Bore x Stroke
3.8 in x 2.4 in (96 mm x 61.5 mm)
Compression Ratio
13.1:1
Power
110.7 hp (81.4 kW) @ 9,000 rpm
Torque
67 lb-ft (91.1 Nm, 9.3 kgm) @ 7,250 rpm
Fuel Injection
Electronic fuel injection system. One injector per cylinder. Full ride-by-wire.
Exhaust
2-1-2 system
Gearbox
6 speed with Ducati Quick Shift up/down 2.0
Primary drive
Straight cut gears; Ratio 1.84:1
Ratio
1=38/14 2=34/17 3=32/20 4=29/22 5=24/21 6=26/25
Final drive
Chain 520; front sprocket 16; rear sprocket 42
Clutch
Hydraulically controlled slipper and self-servo wet multiplate clutch. Self bleeding master cylinder
Frame
Monocoque Aluminum
Front suspension
Showa Ø 43 mm usd fork
Front Wheel
Casted light alloy, 3,50" x 17"
Front Tire
Pirelli Diablo Rosso IV, 120/70 ZR17
Rear suspension
Showa monoshock with adjustable preload. Aluminum double-sided swingarm
Rear Wheel
Casted light alloy, 5,50” x 17”
Rear Tire
Pirelli Diablo Rosso IV, 180/55 ZR17
Wheel Travel (Front/Rear)
5.1 in / 5.7 in (130 mm / 145 mm)
Front Brake
2 x Ø 320 mm semi-floating discs, radially mounted Brembo Monobloc M4.32 4-piston callipers, radial master cylinder. Cornering ABS.
Rear Brake
245 mm disc, 2-piston caliper. Cornering ABS
Instrumentation
Digital dashboard with 5'' full-color TFT display, 800 x 480 px resolution; 16:9 ratio
Dry weight
386 lb (175 kg)
Seat height
32.1 in (815 mm)
Wheelbase
58.7 in (1,492 mm)
Rake
23.3°
Trail
3.6 in (92 mm)
Fuel Tank Capacity
3.7 US gal (14 l)
Number of Seats
2
Safety Equipment
Riding Modes, Power Modes, Ducati Traction Control (DTC), Ducati Wheelie Control (DWC), Engine Brake Control (EBC), Bosch Cornering ABS, Auto tire calibration
Standard Equipment
Ducati Quick Shift (DQS) up/down 2.0, Coming Home, TFT color display, Full LED lighting system, Daytime Running Light (DRL), Self cancelling turn indicators, Lap Timer, Flyscreen, Passenger seat cover
Ready for
Anti-Theft, Tire Pressure Monitoring System (TPMS), Cruise control, Ducati Multimedia System (DMS), Heated grips, Turn-by-Turn navigation system, USB port, Ducati Power Launch (DPL). Availability of some accessories may vary. Please check with your dealer.
Warranty
24 months, unlimited mileage
Annual Service
12 months
Oil Service
9,000 mi (15,000 km) / 24 months
Valve Clearance Check
28,000 mi (45,000 km)
